UL listed fireproof interior metal hospital door for safety good quality 1 hour 2 hours 3 hours, China UL listed fireproof interior metal hospital door for safety good quality 1 hour 2 hours 3 hours Manufacturers, Suppliers, Factory -Shanghai Xunzhong Industry Co., Ltd.

UL Fire Door Specification
Brand	XZIC
Certifications	UL Category Control Number are (R39532/R39533/R39534)
Filler Material	Perlite, honeycomb paper, aluminum silicate cotton etc
Fire rated time	1 hour up to 3 hours
Size	Up to 9’- 5.7"10’-2.2"ft(height) / 28883104mm(height)
Door leaf sheet	22 Ga. -18 Ga. (/1.0/1.2 mm) galvanized steel sheet
Door frame sheet	16 Ga. -14 Ga. (1.5mm-2.0mm) galvanized steel sheet
Surface finish	Door leaf and frame powder coated finish
Opening direction	Swing Inward / Outward
Color	RAL color system, could be customized as well
Accessories	Lock, handle, hinges, door closer, panic bar and other as requested
Vision Panel	With or without as requested
Lite Frame	Frame type can be customized
Louver	With or without as requested
Feature	Fire proof and thermal insulation
Application	building project, business, home decoration(Office, hotel, church, home etc
Package	Inside: PE paper, Outside: double layers carton box and wooden pallet
MOQ	1 Set

Certifications

Xunzhong fire doors started in 2003
These fire doors have excellent quality and reliable fire time, steel door fire time: 90-180 minutes, wood door fire
time: 20-90minutes
In the event of fire can effectively play the role of fire prevention, reduce the loss of personnel and property

Our UL fire door certificate, you can check the corresponding fire certificate according to the number on the UL officialwebsite.
Standards & Certifications
UL 10(c) 、UL 10(b)、 CAN/ULC S104
UL lite frame certificate Number: 20190102-R39533
UL lite frame certificate Number: 20190322-R39532

UL listed fireproof interior metal hospital door for safety good quality 1 hour 2 hours 3 hours factory

UL listed fireproof interior metal hospital door for safety good quality 1 hour 2 hours 3 hours supplier

UL certified fire label

Our UL fire door certificate, you can check the corresponding fire certificate according to the number on the UL officialwebsite
In addition, our fire door has the UL fire label, the label information includes: manufacturer, fire protection time, fire protection certification scope, number and scannable QR code

Steel fire Door - door leaf 2 hours label

UL listed fireproof interior metal hospital door for safety good quality 1 hour 2 hours 3 hours manufacture

Steel fire Door - door leaf 3 hours label

Steel fire Door - door frame 2 hours label

Steel fire Door - door frame 3 hours label

Products Description

UL STEEL FIRE DOOR

Certified with ANSI/UL10C UL10B

CAN/ULC-S104/EN/BS

1 hour up to 3 hours fire rating

Max Size：9’- 5.7"*10’-2.2"ft(height) / 2888*3104mm(height)

What Is on the Inside of Commercial Steel Doors?

Steel fire doors are a great option for many facilities in order to ensure safety and security
However, you may be asking yourself: what types of wooden doors exist and how do I choose? We are happy to assist you in fitting your application needs
In general, our main filling materials are: honeycomb paper, rock wool, perlite, polyurethane
and other materials

Hardware accessories

About our hardware fittings

The use of high quality material, will not cut corners, in different functions of the use of the door will have different styles and use of hardware, support customer customization or match

Steel fire door type

Refer to the picture on the right, the door body can be added: louvers, fire Windows, line modeling, etc

Note: Some special designs do not meet UL specifications, please consult us for details

Figure shows: TOP view, hinge opening, lock opening, in addition, XZIC American standard fire door can be customized for you according to your hardware requirements CAD drawing, so that you can better understand your fire door, to help production cooperation

Optional door frame type: hollow metal frame or wood frame Door lock type: Narrowline Aluminum、Cylindrical、Mortise、Mortise Exit Device，etc. For more hardware types please contact us

Select your door opening direction

In this part, you can learn more about the opening direction of the door and choose the way of opening inside or outside. If you have any questions, please consult our customer service. We are happy to serve you

UL listed fireproof interior metal hospital door for safety good quality 1 hour 2 hours 3 hours details

Company Profile

About our factory and service logistics

We support a variety of logistics distribution methods, before packaging will have a rigorous review to ensure that the quality of the goods delivered to you is correct

Company Introduction

Shanghai Xunzhong Industry Co., Ltd is a leading professional manufacturer of fire door&window and other special doors, located in the international metropolis -Shanghai, established in 2003. For promotion of business development, we set up a HongKong company called Branch: Lixin
Our Enterprise has more than 15 years experience with two production bases located in Shanghai and Jiangsu province, annual production capacity could reach 1 million sets of door Main products cover UL&CE fire door&fire window, explosion proof door, sound proof door, hospital door, clean room door and other special door

Benefit from advanced technique and efficient international marketing exploration. Xunzhong has gained good reputationas reliable partner in over 50 countries and regions such as North America, Europe, Australia, South America, Middle East, South Asia, Southeast Aisa, etc.
Xunzhong Products constantly strive to provide professional doors solution by providing premium products at competitive prices

Complete range of production line can meet different requirement from various customers. We sincerely hope to establish lastingbusiness relationships with customers worldwide

Exhibitions

Among foreign exhibition, Xunzhong fire door has been deeply consumer's affection and trust, at the conference by customers in the local countries, due to recent outbreaks, cannot attend overseas exhibitions, but we firmly believe that there will be at the fair and clients meet again opportunity again, welcome to visit our company to negotiate

XZIC wood fire door

Certification UL fire protection standard, BS, CE, ISO9001, SGS, etc

Maximum custom size 8ft * 8 '0.79"ft / 2438x2459mm

Fire protection time 20-90 minutes

Recommend Products

What is a fire door?
A complete installed door assembly comprising door frame, door leaves, hardware, seals and any glazing that, when closed, is intended to resist the passage of fire and smoke in accordance with specified performance criteria
A Fire Door = A complete installed assembly
Purpose of Fire Door
Primary Reason - To save lives & property in the event of a fire
An average of 62 deaths per day in the last 5 years
Designed to keep closed in the event of fire so that the fire should not spread to other areas
Two important functions
1) Compartmentalizing a fire
2) Creating & Protecting an escape route through the building
Fire Risk Assessment = To identify fire resistance of fire door
What is fire rating in fire door?
Resistance to Smoke/Fire for a minimum specified length of time
Fire Ratings are stated in minutes & prefixed by the letters‘FD'
FD30 = 30 minute Fire Door set
One that offers at least 30 minutes of protection against fires
FD30 - 30 minutes
FD60 - 60 minutes
FD90 - 90 minutes
FD120 - 120 minutes
XZIC UL Steel fire doors up to 3 hours rating
Where a fire door can be used
Wherever a fire might start, it is advisable to use a fire door there.
Doors leading from a kitchen, a lounge with a fireplace & TV or any room with electric equipment or flammable items.
About XZIC fire door
XZIC DOORS provides a full line of standard and customized hollow metal doors for construction projects in the commercial, industrial and institutional markets. XZIC doors has been used for hotel, school, apartment, hospital, power plant, e-house, subway station etc.
Standard metal fire doors are 1-3/4" thick. The doors finish with powder coating, which could be
choose from RAL color. Hollow Metal Doors are shown to have superior performance for strength and durability compared to the alternate materials. Metal doors are more sanitary, much easier to maintain. A result of the strength and durability of steel is that metal doors have the lowest total cost of ownership of any other materials. XZIC hollow metal steel fire doors that meet the strict guidelines of Steel Door Institute (SDI), and our doors are tested from UL laboratory, which is pretty hard to success approved by UL company. But we did. XZIC steel fire doors, frames, glass vision, glass vision frame, handle lock, hinges, closer are both get tested by UL company

TFAQ

Q: What is your main product?
A: As China leading manufacturer of special doors, our product range includes fire door, hospital door, ward door, industry cleaning
room door, sound proof door, explosion proof door, explosion relief door, etc.

Q: What kind of Certification do you have?
A: After professional testing by relevant institution, we have got certificates of UL, CE, NFPA, BS, ISO9001, etc

Q: How can I know your price?
A: Tell us your requirement of the specification and the quantity, then we will send quotation to you.

Q: How can you guarantee your product quality?
A: Not only for the product certificates worth your trust, but we adopt quality control by four testing procedures: Initial
inspection, re-inspection, final inspection and sampling inspection to guarantee the quality.

Q: What is your payment terms?
A: Normally, 30% - 50% of total amount by T/T as deposit and balance should be paid before delivery. Irrevocable L/C at sight is
also acceptable.

Q: What is your delivery time?
A: About 15 working days after deposit and drawing confirmed

XZIC

Introducing the UL listed fireproof interior metal hospital door.

A top-quality product designed to prioritize safety durability and longevity in any healthcare facility. Specially crafted to meet the specific needs of medical institutions providing optimal protection against fire and other hazards.

With a fire rating of 1 hour 2 hours or 3 hours depending on your specific requirements this metal hospital door is a reliable solution for optimal protection during emergencies. Constructed with top-grade materials that meet UL-Listed standards ensuring that it can withstand extreme conditions and keep your facility safe.

Built to last which means that you won't have to worry about XZIC frequent repairs or replacements. We understand that hospitals are busy environments that require robust and sturdy fittings that can withstand wear and tear and why we have designed this door with the best materials possible.

Not just for your safety; it ensures privacy and ease of access in the hospital. Made to open in any direction depending on the needs of the facility. Each door is customized to fit any layout and space requirements ensuring seamless integration with your building structure.

At XZIC quality and safety are our top priorities. why our UL listed fireproof interior metal hospital door follows strict standards for safety. Every door is tested rigorously to guarantee it can hold up under all possible conditions that medical facilities might face including fire impact and noise.

designed with an aesthetic flair making it a perfect fit for your hospital's interior design style. Choose from a range of colors and finishes that can match your interior to integrate with the look and feel of your facility.

Grab yours now.
